Forged Piston Set, Lotus Twin Cam 83mm
Forged Piston Set, Lotus Twin Cam 83mm
SKU:7500-FP-83TC
Engineered in house and manufactured by CP/Carrillo, these motorsport grade forged pistons are designed to be used with the standard 72.75mm stroke crankshaft and 4.800" C to C length connecting rods.
Dome height is set at .057” providing a nominal compression of 10:1 allowing the engine to run on 91 octane fuel or higher. Large valve pockets are also included to accommodate high lift camshafts and large valves. Modern piston ring design ensures maximum sealing.
Engine Displacement Bore: 83mm x Stroke 72.75mm - 1575cc
Your engine block will require machining, contact us for details.
- Made in the USA
- Bore 83mm / 3.267"
- Compression height 1.530"
- Dome height .057" (2.67cc)
- Pin diameter .812"
- Pin Oiling feature
- Top Ring 1mm
- Second Ring 1.2mm
- Oil Ring 2.8mm
- Piston Weight 309 grams
